Overrun Device BPW, V, Type ZAF 3,0-3
Prices visible after login
Register now
Register now
Product information "Overrun Device BPW, V, Type ZAF 3,0-3"
Overrun device BPW
for V-drawbar
Type ZAF 3,0-3
Perm. gross weight 1800 – 2800 kg
Nose load 150 kg
with dead-centre hand lever and spring mechanism
support wheel panel facing to the side and backwards
with coupling head WW 30-D3
Lever mounted for wheel brake S1704-7RASK, S2005-7RASK, S2504-7RASK, 2051
suitable for PAV/SR 2,7X
dimensions (see drawing):
A 768 mm
B 305 mm
C 166 mm
D 189-245 mm
E 110-130 mm
ETI 827004
| Bremsentyp: | 2051, S1704-RASK, S2005-7RASK, S2504-7RASK |
|---|---|
| Form: | V-Ausführung |
| Gewicht: | 18.5 |
| Hersteller: | AL-KO, BPW |
| Material: | Stahl |
| Maß A (mm): | 922 |
| Maß B (mm): | 310 |
| Maß C (mm): | 166 |
| Maß D (mm): | 195 |
| Maß E (mm): | 110 |
| Stützlast (kg): | 150 |
| Typ: | ZAF2,8-2 |
| zul. Gesamtgewicht (kg): | 2800 |
